SKU TMG-GWP40

Pompe à pression à piston triplex industriel TMG, max. 4000 PSI, 5 GPM, 3400 tr/min, arbre creux 1", puissance moteur compatible 9-15 HP, TMG-GWP40

Original price $499.00 CAD - Original price $499.00 CAD
Original price
$499.00 CAD
$499.00 CAD - $499.00 CAD
Current price $499.00 CAD
CURRENTLY IN STOCK
+ SHIPPING ( Get FREE SHIPPING on orders over $1000 )

Other financial option:

20.0 lb
13 x 12 x 10 inches
More Shipping Info
  • Compatible with TMG-GWJ36 and TMG-GWS40
  • Durable triplex plunger pump often used for high pressure fluid output
  • Die-cast oil bath crankcase is built for long term lubrication & minimal wear
  • Thermo pump protector & direct drive power transmission
  • 4-bolt engine mounting flange for easy attachment to your equipment

Features

  • Replacement pump for TMG-GWJ36 and TMG-GWS40, as well as most pressure washers with 1” gas engine flange in the fields
  • This durable triplex plunger pump is often used for pumping out fluids at high pressures due to its robust, heavy-duty design
  • Die-cast oil bath crankcase is built for long term lubrication and minimal wear to the attached equipment so you get the best performance from your pump
  • Constructed with a brass manifold, stainless steel valves and a sight glass for you to check your oil levels before/after operation
  • Thermo pump protector and direct drive power transmission from the gas engine or electric motor for maximum power and efficiency
  • Vented oil dipstick prevents heat overflow and heat dissipation cooling fins to keep the pump working even after a grueling long day
  • 4-bolt engine mounting flange makes this pump easy to attach/replace on your equipment so you can quickly get back to work with little down time

Specifications

  • Match engine power: 9-15 HP
  • Max. work pressure: 4000 PSI
  • Max. flow rate: 5 GPM
  • Engine speed: 3400 RPM
  • Hollow shaft: 1”
  • Pump plunger bore: 15 mm
  • Pump stroke: 10 mm
  • Inlet: ¾” NH thread
  • Outlet: ⅜” quick connect
  • Oil plugs: 2
  • Crankcase oil capacity: 16 oz
Pompe à pression à piston triplex industriel TMG, max. 4000 PSI, 5 GPM, 3400 tr/min, arbre creux 1

Shipping Information

The order will ship FREE from one of our main warehouses in Canada or the United States. Under normal circumstances it will take us 2 to 3 business days to process the order and ship it. It will take up to 10 to 15 business days for the order to get to you based on where you are located and how accessible the location is.

  • This product is packed in a carton shipping box
  • Shipping dimension: 13” x 12” x 10” (L x W x H)
  • Shipping weight: 20 lb
Shipping from Richmond BC, Mississauga ON or Montreal QC
In-store pickup is available
What happens after you place your order?
Pompe à pression à piston triplex industriel TMG, max. 4000 PSI, 5 GPM, 3400 tr/min, arbre creux 1

Product Description

La TMG-GWP40 est la pompe de remplacement pour la plupart des nettoyeurs haute pression à essence avec un profil d'arbre creux de 1". Tous les modèles de nettoyeurs haute pression industriels TMG (TMG-GWJ36 et TMG-GWS40) sont équipés de cette pompe pour des performances optimales. Cette pompe à pression triplex est livrée avec un maximum de 4000 PSI et un débit de 5 GPM et une capacité d'huile de 16 oz.

Fabriqué avec des pièces de première qualité telles qu'un collecteur en laiton, des vannes en acier inoxydable, un carter à bain d'huile moulé sous pression et une pompe à piston triplex. Le TMG-GWP40 est également livré avec une jauge d'huile ventilée pour empêcher le débordement de chaleur et des ailettes de refroidissement à dissipation de la chaleur pour qu'il continue de fonctionner même après de longues et dures journées - il est conçu pour faire le travail.

Facile à installer avec sa bride de montage moteur à 4 boulons et sa conception compacte et légère. Cette pompe à pression est pratique, polyvalente et polyvalente d'un travail ou d'un équipement à l'autre.

Warranty

We're here to support you. This product is backed with our 1-year manufacturer warranty. Customer support and spare parts are offered from our headquarters located in Richmond, BC.
