TMG-PSTB160H

160 Gal Boom Sprayer, Hydraulic Folding 40' Boom, 20 GPM, Tractor Mounted 3-Point PTO, TMG-PSTB160H

TMG-PSTB160H hydraulic folding boom sprayer at an angle, showing the green tank, raised folded booms and hoses.
CURRENTLY IN STOCK
SKU TMG-PSTB160H
$6,999.00 CAD - $6,999.00 CAD
$6,999.00 CAD
$6,999.00 CAD - $6,999.00 CAD
$6,999.00 CAD
$6,999.00 CAD

FREE

shipping to most locations in

Canada

Delivered in 10 to 15 business days Learn More
GRAB IT SOON - ONLY 2 LEFT IN STOCK
1-877-761-2819
Product Manual
Find Parts

Features

  • 3-Tank System: Includes a 160 gal chemical tank, circuit-washing tank and hand-washing tank for spraying, system rinsing and operator cleanup.
  • 50 HP Tractor Compatibility: Built for larger tractors requiring reliable boom spraying performance across field treatment and crop care work.
  • 40' Hydraulic Folding Boom: Wide boom coverage allows efficient field spraying, while hydraulic folding simplifies transport, setup and storage.
  • 20 GPM Flow: 24-nozzle setup delivers steady spray output and even coverage across wider treatment areas during crop and field spraying work.
  • Stable Boom System: Balance and shock absorption systems improve boom stability when working over uneven field conditions.
  • 3-Point PTO Mount: Tractor-mounted frame creates a secure hitch connection for stable, dependable PTO-powered operation

Specifications

  • Chemical tank capacity: 160 gal (600 L)
  • Recommended horsepower: 50 HP
  • Hitch compatibility: Category II
  • Pump flow rate: 20 GPM (78 L/min)
  • Number of nozzles: 24
  • Working pressure: 0.3-0.5 MPa
  • Circuit-washing tank capacity: 21.1 gal (80 L)
  • Hand-washing tank capacity: 4.0 gal (15 L)
  • Boom length: 40' (12 m)
  • Fold / lift type: Hydraulic
  • Net weight: 1190 lb (540 kg)
  • PTO shaft: Not Included

Product Description

The TMG-PSTB160H Sprayer is a tractor-mounted PTO sprayer designed for field, crop and property spraying applications. Its large tank capacity provides practical spray volume for covering wider treatment areas with fewer refills, making it suitable for larger acreage and agricultural maintenance work.

A 20 GPM spray system works with 24 nozzles and a 40' hydraulic folding boom to deliver broad, even coverage across the work area. The hydraulic folding design makes boom handling easier during transport, setup and storage, especially when moving between fields or work locations.

Built with balance and shock absorption systems, the TMG-PSTB160H keeps the boom steadier over uneven field conditions. The tractor-mounted frame make it a practical spraying solution for crop treatment, field maintenance and property spraying work where wide coverage and efficient operation are needed.

TMG also carries these models: TMG-PSTB160

Shipping Information

The order will ship from one of our main warehouses in Canada. Under normal circumstances, it will take 2 to 3 business days to process and ship your order. Delivery typically takes 10 to 15 business days, depending on your location and site accessibility.

  • This product is packed in two steel frame shipping boxes
  • Shipping dimensions: Box A: 54" x 46" x 91"; Box B: 102" x 18" x 102" (L x W x H)
  • Shipping weight: 1400 lb
Shipping from Richmond, BC, or Mississauga, ON
What happens after you place your order?

Warranty

We know that when you invest in equipment, you're counting on it to perform day in and day out. At TMG Industrial, that trust means everything to us. That’s why we include a 1-year Warranty with every product we sell—because you deserve confidence with every purchase.

Our warranty is there to make sure your equipment stays reliable across the seasons, covering any issues caused by manufacturing defects in materials or workmanship. From fieldwork to property maintenance, you can count on your TMG equipment to deliver.

More than just warranty coverage, we’re committed to supporting you throughout the life of your machine. Our customer service team is here to help, whether you need technical advice, troubleshooting, or parts support.

For full warranty terms, please see our warranty policy
